ENCODER CABLE 3M SHIELDED, BCH2 MIL CONN

ITM11615
INR12246.3In Stock
Schneider Electric
Select Store
  • B2C
  • B2B
Select Pincode

VW3M8D2AR30Schneider Electric - Servo Drive Acc

Images are for reference only.

  • Part Number:
    VW3M8D2AR30
  • Manufacturer:
  • Description:
    Servo Drive Acc
  • Detailed Description:

    ENCODER CABLE 3M SHIELDED, BCH2 MIL CONN

  • PDF Icon Datasheet
    Authorized IconAuthorized
Franchise : Authorised Distributor

Product Brief

This product is part of the Lexium 28 range, an offer of motion servo drives and servo motors. This is a shielded encoder cordset for BCH2 motors with SinCos single turn encoder. It is equipped with one firewire 6-pin connector (servo drive side) and one MIL 17-pin connector (servo motor side). The encoder cable transmits signals between position sensors of servo motors and their control systems. The cable composition is 5x (2 x 0.13squaremm). It measures 3m long and weighs 1.3kg. It is a connection accessory to the BCH2 servo motors. It is compatible with servo motors type BCH2LH103, /LH203, /MM081, /MM031, /MM052, /MM061, /MM102, /HM102, /MM091, /MM152, /MM202. It plugs into the encoder connector of LXM28 drives and BCH2 servo motors. Lexium 28 servo drives and Lexium BCH2 servo motors are Optimized servo bundles for compact machines. Designed for optimized & cost-effective.

Product Attributes

AttributeValue
brandSchneider Electric

In Stock In Stock : 1

RFQ

This item is sold on RFQ only. Click on "Get Quote" to raise RFQ

Sold In
PCS
Min Order Qty
1
Std Packing Qty
1
HSN Code
85444220
1 item left in Stock
