670ec5cdffb37e002bed5a7dLC1D128P7LC1D128P7

TeSys CONTACTOR 4P

ITM12763
INR9999999Out of Stock
Schneider Electric
Select Store
  • B2C
  • B2B
Select Pincode

LC1D128P7

Images are for reference only.

Franchise : Authorised Distributor

Product Brief

TeSys D contactor, 4 poles (2NO+2NC), for non-inductive load applications up to 25A/690V AC-1. It provides a 230V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Product Attributes

AttributeValue
Rated Operational Voltage(Ue)<=300VDC,<=690VAC 25..400hz
RangeTeSys
ApplicationResistive Load
Poles4P
Utilisation CategoryAC-3,AC-3e,AC-4,AC-1
Control Circuit Voltage230VAC 50/60hz
Rated Operational Current(Ie)25 A (at <60 �C) at <= 440 V AC AC-1 for power circuit
brandSchneider Electric
In Stock

This item is sold on RFQ only. Click on "Get Quote" to raise RFQ

Sold In
PCS
Min Order Qty
1
Std Packing Qty
1
Lead Time
5 Weeks
HSN Code
85365010

Standard Lead Time: 5 Weeks
